STANDARD FEATURES INCLUDE

Door safety switches
Top Mounted Controls and Electrical Control Gear, away from water splash, easy access for Servicing
Machine operation inter-locked to Rinse Temperature
Fully panelled front and sides (avoiding water splash to motors etc. when dish wash area is being cleaned)
Capacity up to 220 racks per hour
Clutch controlled conveyor (providing protection to drive mechanism if racks jam in machine)
Low water protection (to wash tank elements)
Integral rinse booster heater 12kW
Wash and rinse elements fitted with individual thermostats
Rinse economiser (pre-set to provide precise volume of rinse water irrespective of fluctuation in water supply pressure)
Maximum Water Consumption 590 Litres per hour
OTHER OPTIONS

Extension Hoods and Vent Spigots at entry and exit ends
Angle Feed Unit
90° Entry and/or Exit Curves (powered by dishwasher)
180° Entry Curve (powered by dishwasher)
180° Entry and/or Exit Curves (self-powered)
12 kW or 15 kW High Velocity Blower Dryer
Heat and Sound Insulating Panels
Rinse Pressure Booster Pump
Exit Bench (proximity) Trip Switch pre-wired into control box. This provides automatic shut down whenever exit bench becomes full
Dimensions (WxDxH): 2500 x 730 x 1600
