- Door safety switches
- Top Mounted Controls and Electrical Control Gear, away from water splash, easy access for Servicing
- Machine operation inter-locked to Rinse Temperature
- Fully panelled front and sides (avoiding water splash to motors etc. when dish wash area is being cleaned)
- Capacity up to 175 racks per hour
- Clutch controlled conveyor (providing protection to drive mechanism if racks jam in machine)
- Low water protection (to wash tank elements)
- Integral rinse booster heater 12 kW
- Wash and rinse elements fitted with individual thermostats
- Rinse economiser (pre-set to provide precise volume of rinse water irrespective of fluctuation in water supply pressure)
- Maximum Water Consumption 480 Litres per hour
- Rack Size: 500 x 500mm
- Capacity 160-175 Racks per hour
- Electrical Connection: 415V/50Hz/3N
- Rating: 24.5 kW
- Water Supply: 2-4 bar, 60°C-65°C min
- Water Consumption: 480L per hour
- Conveyor Drive: 180 watts (with safety clutch)
- Pump Motor Capacity: 2.2kW
- Water Heater: 9.0kW
- Rinse Temperature: 82°C minimum
- Watermark Approval: WM–022833
- HACCP Approval: PE-388-GE-09
- Made in Australia
- 12 Months Parts and Labour Warranty
- Dimensions: (WxDxH) 1820 x 730 x 1600mm
