Description
STANDARD FEATURES INCLUDE
- Door safety switches
- Top Mounted Controls and Electrical Control Gear, away from water splash, easy access for Servicing
- Machine operation inter-locked to Rinse Temperature
- Fully panelled front and sides (avoiding water splash to motors etc. when dish wash area is being cleaned)
- Capacity up to 175 racks per hour
- Clutch controlled conveyor (providing protection to drive mechanism if racks jam in machine)
- Low water protection (to wash tank elements)
- Integral rinse booster heater 12 kW
- Wash and rinse elements fitted with individual thermostats
- Rinse economiser (pre-set to provide precise volume of rinse water irrespective of fluctuation in water supply pressure)
- Maximum Water Consumption 480 Litres per hour
OTHER OPTIONS
- Extension Hoods and Vent Spigots at entry and exit ends
- Angle Feed Unit
- 90° Entry and/or Exit Curves (powered by dishwasher)
- 180° Entry Curve (powered by dishwasher)
- 180° Entry and/or Exit Curves (self-powered)
- 12kW or 15kW High Velocity Blower Dryer
- Heat and Sound Insulating Panels
- Rinse Pressure Booster Pump
- Exit Bench (proximity) Trip Switch pre-wired into control box. This provides automatic shut down whenever exit bench becomes full
Dimensions (WxDxH): 1820 x 730 x 1600 mm
